MAG-26V-400 Final Drive for 3.5-4.5 Ton Excavators | Travel Motor GHS-04

Info.

• Model: GHS-04

• Interchangeable with: MAG-26V-400, GM04A, 702C2K, PGR402

• Lead time: 7 days

• Warranty: 1 year

• Max Output Torque (Nm): 4200

• Max Working Pressure (Mpa): 24.5

• Max Output Speed (r/min): 55

• Applicable Tonnage(T): 3.5-4.5T

Specification

• Motor Displacement: 24/14 cc/r

• Working pressure: 21 Mpa

• Speed control pressure: 2~7 Mpa

• Ratio options: 52.7

• Max. torque of Gearbox: 4200 N.m

• Max. speed of Gearbox: 54 rpm

• Machine application: 3.5~4.5 Ton

Interface

• Frame connection diameter: 165mm

• Frame flange bolt: 9-M12

• Frame flange P.C.D.: 192mm

• Sprocket connection diameter: 210mm (204mm)

• Sprocket flange bolt: 9-M12 (12-M12 optional)

• Sprocket flange P.C.D.: 232mm

• Flange distance: 70mm

• Approximate weigth: 52kg (115lbs)

This item has similar dimensions to most famous brands in the market like Nachi Travel Motor, KYB Travel Motor, Eaton Track Drive, and other Final Drives. It is widely used in the OEM and aftermarket to replace Nachi, Kayaba, Eaton, Nabtesco, Doosan, Bonfiglioli, Brevini, Rexroth, Kawasaki, Teijin Seiki, Tong Myung and other Hydraulic Final Drive Motors.
